Features for the SN65HVD256

• Meets the Requirements of ISO11898-2
• Turbo CAN:
  • Short and Symmetrical Propagation Delay
    Times and Fast Loop Times for Enhanced
    Timing Margin
  • Higher Data Rates in CAN Networks
• I/O Voltage Range Supports 3.3-V and 5-V MCUs
• Ideal Passive Behavior When Unpowered
  • Bus and Logic Pins are High Impedance (No
    Load)
  • Power Up and Power Down With Glitch-Free
    Operation on Bus
• Protection Features
  • HBM ESD Protection Exceeds ±12 kV
  • Bus Fault Protection –27 V to 40 V
  • Undervoltage Protection on Supply Pins
  • Driver Dominant Time Out (TXD DTO)
  • SN65HVD257: Receiver-Dominant Time Out
    (RXD DTO)
  • SN65HVD257: FAULT Output Pin
  • Thermal Shutdown Protection
• Characterized for –40°C to 125°C Operation

Description for the SN65HVD256

This CAN transceiver meets the ISO1189-2 High Speed CAN (Controller Area Network) Physical Layer standard. It is designed for data rates in excess of 1 Mbps for CAN in short networks, and enhanced timing margin and higher data rates in long and highly-loaded networks. The device provides many protection features to enhance device and CAN-network robustness. The SN65HVD257 device adds additional features, allowing for easy design of redundant and multitopology networks with fault indication for higher levels of functional safety in the CAN system.
